20° angulation for posterior access
Each osteotome is angled at 20° — geometry-matched to the posterior mandibular corridor. The working tip aligns with the site axis while the handpiece body clears the cheek and ramus.
OSSEOTOUCH · Magnetic Mallet System
Kit Easy In 6
Working the mandible with the Magnetic Mallet
Mandibular Osteotome Kit · six 20° angled osteotomes for D2-D3 bone preparation
Six 20° angled osteotomes — AZ 100P pilot through AZ 300 — designed by Dr. Arduini and Dr. Zuccaro for posterior mandibular implants and full-arch six-implant workflows. Magnetodynamic bone distraction, no rotary cutting.
Mandibular preparation·D2-D3 bone·20° angulation·Six osteotomes·Magnetodynamic·Bone distraction·Immediate loading·Full-arch six-implant·Mandibular preparation·D2-D3 bone
01 The clinical problem
Rotary drills
fight the dense mandible
Dense D2 and D3 mandibular bone resists rotary cutting. The blade scrapes the bone, generates friction heat, and demands continuous high-volume irrigation to stay safe. Posterior sites add a second problem: the cheek, the ramus, and the buccal corridor restrict access — straight instruments can't reach where they need to with the right insertion axis.
02 The Easy-In approach
20° osteotomes
made for the mandible
Six 20° angled osteotomes advance through 50-microsecond magnetodynamic impulses delivered by the Magnetic Mallet. Bone is distracted laterally rather than cut, the osteotomy wall is preserved, and the angled geometry reaches posterior mandibular sites without compromised insertion axes. Designed by Dr. Arduini and Dr. Zuccaro around the full-arch six-implant mandibular workflow.
02 Six benefits
Six benefits
of magnetodynamic mandibular preparation
One handpiece. Six osteotomes. Six reasons site preparation in dense mandibular bone becomes faster, more predictable, and reaches sites rotary protocols struggle with.
Bone distraction, not subtraction
Magnetodynamic impulses push the bone laterally rather than cutting it away. The osteotomy wall matrix is preserved — typically supporting the high seating torque associated with immediate-loading workflows.
Avoids rotary friction heat
The osteotomes do not rotate. The non-rotary action avoids the friction heat rotary drills generate in dense D2-D3 bone — and the high-volume irrigation cycle that comes with it.
Calibrated, operator-independent force
The 50-microsecond impulse is delivered by the device, not by hammer strikes from an assistant. Insertion energy is consistent from the first osteotome to the sixth — and stays below the threshold typically perceived as vibration.
Six progressive diameters
From AZ 100P pilot through AZ 300 — narrow-platform to wider-platform implants covered by a single kit. The surgeon dials in the final diameter precisely, without changing kits mid-case.
Designed by Dr. Arduini & Dr. Zuccaro
Diameter sequence and 20° geometry come from Dr. Luca Arduini and Dr. Daiana Zuccaro, Italian implantologists with active practice in full-arch and immediate-loading mandibular cases.
03 Easy-In at work
Clinical case
in real practice
Documented clinical case — Dr. Luca Arduini using Kit Easy In 6 on a posterior mandibular preparation with the OSSEOTOUCH Magnetic Mallet, including immediate-loading workflow.
Bring magnetodynamic mandibular preparation
to your practice
Talk with our specialist to evaluate Kit Easy In 6 for your mandibular case mix, check compatibility with your existing Magnetic Mallet handpiece, or request a demo on a full-arch six-implant workflow.
04 The Surgical Kit · 6 osteotomes
Six osteotomes
one mandibular sequence
AZ 100P pilot through AZ 300 — six 20° angled osteotomes covering the typical mandibular implant diameter range. The kit pairs with a Magnetic Mallet handpiece via the standard threaded coupling.
Six osteotomes (one set)
Six 20° angled osteotomes in a surgical-grade autoclavable box. Each osteotome threads onto the Magnetic Mallet handpiece via the standard threaded coupling. Reusable case after case with standard autoclave sterilization.
AZ sequence — pilot to AZ 300
| Code | Role | Use in sequence |
|---|---|---|
| AZ 100P | Pilot | Marks entry point and establishes the insertion axis in the mandibular crest |
| AZ 100 | Initial expansion | First diameter step after the pilot |
| AZ 160 | Intermediate expansion | Progressive lateral distraction toward planned implant diameter |
| AZ 200 | Working expansion | Common final preparation diameter for narrow-platform implants |
| AZ 230 | Wider expansion | Standard-platform implants in mandibular sites |
| AZ 300 | Final expansion | Wider-platform implants when planned by the surgeon |
Surgical-grade stainless steel, autoclavable. Compatible with new-generation Magnetic Mallet handpieces; the Plus handpiece is recommended for dense D2-D3 mandibular bone.
U.S. orders · available now
Order Kit Easy In 6 through OSSEOTOUCH USA — fast nationwide delivery, dedicated clinical support.
05 Clinical applications
Four clinical applications
one mandibular workflow
Kit Easy In 6 covers the mandibular implant scenarios where rotary preparation is most challenging — same six-osteotome sequence, same magnetodynamic principle, same handpiece.
Posterior mandibular implants
Sites 36-37, 46-47 — dense D2/D3 bone, restricted buccal corridor, lingual concavity. The 20° angulation reaches distal sites with the correct insertion axis; bone distraction supports the seating torque needed for stable placement.
Immediate-loading workflows
Lateral bone distraction preserves the osteotomy wall matrix rather than removing it. In dense D2-D3 sites this commonly supports the seating torque range typically associated with immediate-loading workflows. Final stability is always a clinical assessment.
Narrow ridges in the mandible
In suitable cases, magnetodynamic osteotomes can gradually distract a narrow mandibular ridge as the diameter sequence progresses. May avoid or postpone formal ridge-splitting or bone-grafting in selected scenarios.
Full-arch six-implant protocols
Six osteotomes for six implants. The 20° angulation handles distal sites without changing instruments; magnetodynamic advancement reduces per-site preparation time across the full surgical session.
U.S. orders · ships nationwide
Add Kit Easy In 6 to your mandibular workflow — order through OSSEOTOUCH USA, fast nationwide delivery.
06 Frequently asked questions
Common questions
about Kit Easy In 6
What is Kit Easy In 6 and what is it used for?
Kit Easy In 6 is a six-osteotome mandibular set designed by Dr. Luca Arduini and co-designed by Dr. Daiana Zuccaro for implant site preparation in dense D2 and D3 mandibular bone using the OSSEOTOUCH Magnetic Mallet. The six 20° angled osteotomes (AZ 100P pilot, AZ 100, AZ 160, AZ 200, AZ 230, AZ 300) progressively expand the osteotomy through bone distraction, replacing rotary subtraction in posterior mandibular sites and full-arch six-implant mandibular workflows.
Why six osteotomes specifically?
Six osteotomes match a clinical reality: the typical full-arch six-implant mandibular case places six implants, and the diameter sequence (pilot through AZ 300) covers narrow-platform to wider-platform implants without changing kits mid-case. The number and the diameter spread are set by the kit's designers, Dr. Arduini and Dr. Zuccaro, based on full-arch mandibular workflow experience.
Why 20° angulation?
Posterior mandibular sites cannot reliably accept a straight insertion axis: the cheek, the buccal corridor, and the ramus geometry restrict access. A 20° angled osteotome aligns the working tip with the site axis while keeping the handpiece body clear of soft tissues, allowing posterior sites to be prepared with the correct vertical axis.
How does Easy In 6 compare to rotary drills?
Rotary drills cut and remove bone, generating friction heat in dense D2/D3 mandible. Easy In 6 osteotomes do not rotate — they advance through magnetodynamic impulses and laterally distract the bone, preserving the osteotomy wall matrix and avoiding rotary heat. Lateral distraction also commonly supports the higher seating torque used in immediate-loading workflows.
Can Easy In 6 be used for immediate loading?
Easy-In supports immediate-loading-friendly preparation by preserving the osteotomy wall and producing a slightly under-prepared site. Whether immediate loading is appropriate is always a clinical decision based on the achieved primary stability, the bone quality, the implant system, and the prosthetic plan — not on the kit alone.
Is Easy In 6 only for the mandible?
Yes — by design. The 20° angulation, the diameter sequence, and the entire kit philosophy are mandibular. Maxillary preparation typically requires different geometry. For osseodensification in the maxilla we recommend other dedicated kits in the OSSEOTOUCH catalog.
Is Easy In 6 compatible with my Magnetic Mallet handpiece?
Compatible with new-generation Magnetic Mallet handpieces; the Plus handpiece is recommended for dense D2-D3 mandibular bone. Each osteotome threads onto the handpiece via the standard threaded coupling and is advanced by the magnetodynamic impulse. No additional accessory is required beyond the kit and the handpiece.
What is the FDA regulatory status of the Magnetic Mallet system?
The OSSEOTOUCH Magnetic Mallet is registered with the U.S. FDA under Establishment Registration 3011922183 and product codes EIS · KDG · GEY (21 CFR 872.4565 / 878.4820). U.S. Agent: Thema USA, New York. The Easy-In osteotomes thread onto new-generation Magnetic Mallet handpieces and are fully autoclavable.
Ready to get started?
Talk with our team — we'll help you evaluate Kit Easy In 6 for your mandibular workflow and run a demo at your office or via video call.
Book a clinical call
Pick a date and time. We will contact you to discuss your workflow.
Email our specialists
cs@osseotouch.com
Direct chat with our team.
U.S. ordersBuy online
Order Kit Easy In 6 through OSSEOTOUCH USA — fast nationwide delivery and clinical support.
Kit Easy In 6 is part of the OSSEOTOUCH Magnetic Mallet system, manufactured by Meta Ergonomica S.r.l. (Italy). United States: registered with the U.S. FDA under Establishment Registration 3011922183 and product codes EIS · KDG · GEY (21 CFR 872.4565 / 878.4820). U.S. Agent: Thema USA, New York. ISO 13485. Use restricted to qualified dental professionals according to the instructions for use.
