3D animation · OSSEOTOUCH Magnetic Mallet
PT1 — Pterygoid implant
Step-by-step 3D animation of the magnetodynamic pterygoid sequence — the osteotomes (PT1 → PT2 → PT3) advancing through the cancellous corridor toward the pyramidal process.
OSSEOTOUCH · Magnetic Mallet System
PT-1 Pterygoid Implant Kit
On-axis pterygoid placement · magnetodynamic bone condensation
Pterygoid Implant Kit · 3 dedicated osteotomes (PT1, PT2, PT3) · 2 extended pterygoid drills · RADEL autoclavable case
A pterygoid implant kit designed for magnetodynamic site preparation with the OSSEOTOUCH Magnetic Mallet. The 3 dedicated osteotomes advance through the cancellous bone of the pterygoid corridor toward the pyramidal process by axial bone condensation rather than rotary subtraction — preserving the bone matrix, supporting axis control, and aiming to reduce the trajectory drift that compromises pterygoid implant outcomes.
Pterygoid implant kit·Magnetodynamic bone condensation·Axis control·Pyramidal process·Atrophic posterior maxilla·Full-arch fixed prosthesis·Tuberosity implant·Sinus-lift alternative·Pterygoid implant kit
01 The clinical problem
In the pterygoid corridor
a few degrees decide everything
Pterygoid implant placement requires the surgeon to maintain a single rigorous trajectory across multiple bony layers — through the maxillary tuberosity, into the pterygoid plate, and toward the pyramidal process. Rotary drills work by subtraction and tend to follow the path of least resistance through soft cancellous bone, drifting off the planned axis. Frictional heat at the cancellous-cortical interface adds a thermal risk in a region where the bone is heterogeneous (D1 cortical pterygoid plate + soft cancellous tuberosity).
02 The PT-1 approach
A magnetodynamic kit
that condenses, doesn't drill
PT-1 replaces rotary subtraction with magnetodynamic bone condensation in the pterygoid corridor. The 3 dedicated osteotomes (PT1, PT2, PT3) advance through the cancellous bone by lateral expansion — preserving the bone matrix and providing controlled axial advancement. Two extended pterygoid drills address the dense cortical plate when needed. Two parallelism pins support trajectory verification during key preparation steps.
02 PT-1 at work
Watch the
magnetodynamic pterygoid sequence
3D animation of the PT-1 kit in action — the magnetodynamic osteotome sequence (PT1 → PT2 → PT3) advancing through the pterygoid corridor toward the pyramidal process.
03 Clinical cases in practice
Documented clinical cases
by international clinicians
Two documented clinical cases of magnetodynamic pterygoid implant placement with the PT-1 kit.
04 Six benefits
Six benefits
of magnetodynamic pterygoid preparation
One handpiece. One pterygoid kit. Six reasons pterygoid implant placement becomes more axis-controlled and bone-preserving than conventional rotary protocols.
Axis control to the pyramidal process
Magnetodynamic advancement gives controlled axial feedback between impulses. The system is designed to help maintain the planned trajectory through the cancellous corridor.
Bone condensation, not subtraction
Cancellous bone is laterally compacted along the pterygoid corridor instead of being removed. Bone matrix preserved, peri-implant density supported.
Avoids rotary friction heat (osteotome phase)
Magnetodynamic osteotome phase avoids rotary friction heat; when extended drills are used on the cortical plate, standard rotary irrigation practices apply.
Extended pterygoid drills for D1 cortex
Two extended-height pterygoid drills handle the dense cortical pterygoid plate. Designed for the depth requirements of the pterygoid corridor.
Parallelism pins for trajectory verification
Two parallelism pins support trajectory verification during key preparation steps — allowing course corrections before the implant is committed.
Complete in one autoclavable RADEL case
3 osteotomes + 2 drills + 2 pins + drivers + length measurer + adjustable torque wrench, organized in a RADEL autoclavable case.
Bring magnetodynamic pterygoid surgery
to your practice
Talk with our specialist to evaluate PT-1 for your pterygoid implant workflow, check compatibility with your existing Magnetic Mallet handpiece, or request a demonstration.
05 The kit · 3 osteotomes + 2 drills + accessories
One kit
for the pterygoid corridor
Everything required for the magnetodynamic preparation of the pterygoid implant site, organized in a single autoclavable RADEL case.
3 dedicated osteotomes
| Code | Role in sequence |
|---|---|
| PT1 | First entry into the pterygoid corridor, axis establishment |
| PT2 | Progressive cancellous bone condensation toward the pyramidal process |
| PT3 | Final-diameter preparation, axis verification before fixture placement |
2 extended pterygoid drills
Increased height profile dimensioned for the cortical pterygoid plate depth, with handpiece clearance for the pterygoid corridor.
Accessories included
2 parallelism pins for trajectory verification · 1 contra-angle driver · 1 removable tray · 1 length measurer · 1 prosthetic-component driver · 1 fixture driver (torque-wrench connection) · 1 adjustable torque wrench.
Case: RADEL autoclavable surgical case (full kit organization). Reusable surgical components autoclavable according to the manufacturer's IFU. Compatible with new-generation Magnetic Mallet handpieces (osteotomes thread via standard threaded coupling).
U.S. orders · available now
Order PT-1 through OSSEOTOUCH USA — fast nationwide delivery, dedicated clinical support.
06 Clinical applications
Four clinical applications
one pterygoid workflow
PT-1 covers the pterygoid implant scenarios where rotary subtraction or generic kits are most likely to compromise axis control or primary stability.
Atrophic posterior maxilla — sinus-lift alternative
Pterygoid implant placement provides distal anchorage in atrophic posterior maxilla. In selected cases, the pterygoid trajectory may avoid the need for sinus elevation surgery — subject to clinical judgment.
Full-arch fixed prosthesis (All-on-X)
Distal pterygoid anchorage in full-arch fixed-prosthesis workflows. Two posterior implants engaging the pterygoid plate provide cantilever support for the full-arch prosthesis.
Tuberosity implant placement
Implant placement engaging the maxillary tuberosity and the pterygoid corridor where conventional posterior implant sites are not viable due to insufficient bone height.
Avoiding sinus elevation in selected cases
When the planned pterygoid trajectory provides sufficient cortical anchorage and the maxillary sinus floor is not in the implant path, may support an approach that avoids sinus elevation. Subject to clinical judgment.
U.S. orders · ships nationwide
Add PT-1 to your pterygoid implant workflow — order through OSSEOTOUCH USA, fast nationwide delivery.
07 Frequently asked questions
Common questions
about PT-1
What is the PT-1 kit and what is it used for?
PT-1 is a pterygoid implant kit designed for magnetodynamic site preparation with the OSSEOTOUCH Magnetic Mallet. The 3 dedicated osteotomes (PT1, PT2, PT3) advance through the pterygoid corridor toward the pyramidal process by bone condensation rather than rotary subtraction. Indicated for atrophic posterior maxilla, full-arch fixed-prosthesis workflows, tuberosity implant placement, and selected cases where sinus elevation can be avoided.
How is magnetodynamic preparation different from conventional rotary pterygoid drilling?
Rotary drills work by subtracting bone and tend to follow the path of least resistance through cancellous tissue, generating frictional heat. Magnetodynamic osteotomes laterally condense the cancellous bone along the planned trajectory, preserve the bone matrix, and provide controlled axial advancement. The magnetodynamic osteotome phase avoids rotary friction heat; when the extended drills are used on the cortical pterygoid plate, standard rotary irrigation practices apply.
What does the PT-1 kit contain?
Three dedicated osteotomes (PT1, PT2, PT3), two extended-height pterygoid drills for the D1 cortical pterygoid plate, two parallelism pins for trajectory verification, one contra-angle driver, a removable tray, a length measurer, drivers for prosthetic components and fixture (with torque-wrench connection), and one adjustable torque wrench. All in a RADEL autoclavable case.
Is PT-1 a sinus-lift alternative?
In selected cases, yes — when the planned pterygoid trajectory provides sufficient cortical anchorage at the pyramidal process and the maxillary sinus floor is not in the implant path, the pterygoid placement may avoid the need for sinus elevation surgery. The decision is always clinical and case-specific, based on CBCT planning and anatomic assessment.
Can PT-1 be used in full-arch fixed-prosthesis workflows?
Yes. Distal pterygoid anchorage is a recognized strategy in full-arch fixed-prosthesis (All-on-X) workflows, where two posterior implants engaging the pterygoid plate provide cantilever support for the prosthesis. PT-1 is purpose-designed for this scenario — including extended-height drills, parallelism pins, and dedicated osteotomes.
Why are the pterygoid drills 'extended height'?
The pterygoid corridor requires drills with an increased height profile to reach the dense cortical pterygoid plate at depth without the handpiece interfering with the patient's anatomy. The two extended pterygoid drills in the PT-1 kit are dimensioned specifically for the depth requirements of pterygoid implant placement.
Is the PT-1 kit autoclavable?
Yes. The reusable surgical components and the RADEL surgical case are autoclavable according to the manufacturer's IFU. Compatible with new-generation Magnetic Mallet handpieces via the standard threaded coupling.
What is the FDA regulatory status of the Magnetic Mallet system?
The OSSEOTOUCH Magnetic Mallet is registered with the U.S. FDA under Establishment Registration 3011922183 and product codes EIS · KDG · GEY (21 CFR 872.4565 / 878.4820). U.S. Agent: Thema USA, New York. The PT-1 kit instruments thread onto new-generation Magnetic Mallet handpieces.
